Complete stroke connector in one movement
Reach yield stress of mechanical override rods
Field proven
The 4” Collet Connector Mechanical Override tool has been designed to suit subsea trees.
Complete stroke connector in one movement
Reach yield stress of mechanical override rods
Field proven
The override tool interfaces with the two 1” mechanical override rods that protrude from the top of the flowline connector. It uses two hydraulic cylinders to raise the locking ring inside the flowline connector and release the connector. The tool is designed to replace diver-operated tools, allowing a greater force to be applied to the mechanical override rods than was previously possible.
Dimensions (mm): 940 (L) x 402 (W) x 445 (H)
Weight in Air: 60 kg
Weight in Seawater: 49 kg
Max. Pressure: 700 bar (10,000 psi)
Cylinder Stroke: 152 mm (6”)
Connector Stroke : 89 mm (3.5”)
Maximum Depth: Unlimited
